CXY·W-600型

磁、硼铁矿精选机
磁、硼铁矿精选机

产品介绍

CXY·W-600型


CXY·W-600型

CXY . W-600型系列单滚筒磁选机属于精选设备。磁感应强度根据现场矿物的性质和工艺要求设计。该设备磁系采用动态磁系,由永磁滚筒,滚筒无级调速传动装置,电机振动给料装置,磁系摇摆装置等组成,该设备结构紧凑,给料均匀,运转可靠,调整维修方便。公司备有工业样机,可为用户提供小型工业试验,本产品主要适用于下列范围:

◆用于磁选厂精粉提纯作业,抛除铁精粉中的贫连生体及脉石,提高精粉等级,选出超纯铁精粉,增加选厂产品技术附加值。

◆用于磁铁矿,硼铁矿,含铁尘泥,钢渣,粉末冶金等矿物的干选作业,直接生产出铁精粉,具有工艺简单,节约水资源,不产生二次污染,钢渣处理可达到零排放,保护了人类的生存环境。

◆用于硫酸矿渣干粉的磁选提纯。

◆用于非磁性矿矿物的除铁作业。

CXY●W-600 Series single - drum magnetic separator is selected equipment, Magnetic field intensity according to the nature and mineralrequirements of the design process. The device uses the dynamic magnetic system magnetic system by the magnetic roller, roller variablespeed drives, motor vibrating feeding device, magnetic system composed of swing device, the device is compact and uniform feeding,reliable operation, easy maintenance adjustment。Companies with industrial prototype, provides users with small-scale industrial trials, thisproduct is mainly applied to the following areas:

◆Powder used for magnetic separation plant purification operation, cast iron powder in addition to the poor even with the body andgangue, improve powder grade, selected ultra- pure iron powder, to increase technical value-added product processing plant.

◆For magnetie, iron boron, iron dust and mud, slag, powder metallurgy and other minerals dry separation operations, the directproduction of iron powder with a simple process, saving water, no secondary pollution, slag processing can achieve zero emissions,protection of human living environment.

◆Dry magnetic separation for purification of sulfuric acid slag.

◆For non-magnetic iron minerals mining operations.


CXY·W-600型

CXY·W-600型
